ESG-618~2040 - Surface Grinding Machine

Product Specification

Model　 UF-618/618M
ESG-618/618M
ESG-1A618/2A618		 ESG-618ASD
ESG-618ASDII
Table size (mm) 152x460 152x460
Max. grinding length Longitudinal (mm) 480 480
Max. grinding width Crosswise (mm) 178 178
Max. distance from table surface to spindle centerline (mm)　 460 460
Standard magnetic chuck size (mm) 152x350 152x350
Grinding spindle drive Speed 60HZ, 3450rpm; 50HZ, 2850rpm
Power rating (HP) 2.0 2.0
Standard grinding wheel Diameter (mm) 203 203
Width (mm) 12.7mm, Max. 19mm
Bore (mm) 31.75 31.75



Model　 UF-818M
ESG-818/818M
ESG-1A818/2A818		 ESG-3A818
ESG-818ASD
ESG-818ASDII		 ESG-1020M
ESG-1A1020
ESG-2A1020		 ESG-3A1020
ESG-1020ASD
ESG-1020ASDII
Table size (mm) 203x460 203x460 254x508 254x508
Max. grinding length Longitudinal (mm) 480 480 520 520
Max. grinding width Crosswise (mm) 228 228 280 280
Max. distance from table surface to spindle centerline (mm)　 460 460 500 500
Standard magnetic chuck size (mm) 200x450 200x450 250x500 250x500
Grinding spindle drive Speed 60HZ, 5-25m/min; 50HZ, 5-20m/min
Power rating (HP) 2.0 2.0 3.0 3.0
Standard grinding wheel Diameter (mm) 203 203 203 203
Width (mm) 12.7mm, Max. 19mm 19mm, Max, 25mm
Bore (mm) 31.75 31.75 31.75 31.75



Model　 ESG-2A1224 ESG-3A1224
ESG-1224ASDII
ESG-1224ASD		 ESG-3A1228
ESG-1228ASD
ESG-1228ASDII		 ESG-3A1236
ESG-1236ASD
ESG-1236ASDII
Table size (mm) 300x600 300x600 305x712 305x915
Max. grinding length Longitudinal (mm) 600 600 600 915
Max. grinding width Crosswise (mm) 300 300 330 330
Max. distance from table surface to spindle centerline (mm)　 585 585 630 630
Standard magnetic chuck size (mm) 300x600 300x600 300x700 300x800
Grinding spindle drive Speed 60HZ, 1750rpm; 50HZ, 1450rpm
Power rating (HP) 5.0 5.0 5 5
Standard grinding wheel Diameter (mm) 304 304 355 355
Width (mm) 31.75 31.75 50 50
Bore (mm) 76.2 76.2 127 127



Model ESG-3A1632
ESG-1632ASD
ESG-1632ASDII		 ESG-3A1640
ESG-1640ASD
ESG-1640ASDII		 ESG-3A2040
ESG-2040ASDII
Table size (mm) 406x1020 406x1020 506x1020
Max. grinding length Longitudinal (mm) 813 1020 1020
Max. grinding width Crosswise (mm) 410 410 500
Max. distance from table surface to spindle centerline (mm)　 630 630 630
Standard magnetic chuck size (mm) 400x800 400x1000 500x1000
Grinding spindle drive Speed 60HZ, 1750rpm; 50HZ, 1450rpm
Power rating (HP) 5 5 7 1/2HP
Standard grinding wheel Diameter (mm) 355 355 355
Width (mm) 50 50 50
Bore (mm) 127 127 127
