| Model | BS-760M |
|---|
| Mitre cutting at 90°(mm) |
●460■460◎460□ / H beam 760Wx400H |
| Mitre cutting at 60°(mm) |
●420■420◎420□ / H beam 590Wx400H |
| Mitre cutting at 45°(mm) |
●330■330◎330□ / H beam 500Wx400H |
| Mitre cutting at 30°(mm) |
●220■220◎220□ / H beam 220Wx400H |
| Blade size (mm) |
41Wx1.3tx5500L |
| Blade speed (m/min) |
25, 32, 42, 55, 70, 80
Variable speed 25-80 (opt.) |
| Motor output (HP) |
Blade 7.5, Hyd. 2, coolant 1/4 |
| Shipping volume (mm) |
2880x2020x1700 |
| N.W./G.W. (kg) |
2600/2900 |
