UM-30 - Thread Rolling Machine

Product Specification

Model UM-30
Diemeter range of threads rolled Ø5-Ø30
Range of pitch rolled 0.8P-3.5P
Max. length of thread rolled in feed and thru feed both available
Speeds of dies 30-65rpm
Max. diameter Ø148
Bore of cylinderical dies Ø54 keyway 10x5
Width of cylindrical dies 35mm, 70mm
Max. min. center distance of die-spindles 185-142mm
Output(pcs/min) 4~20
Swivelling angle ±7°
Machine motor 5HP (3.7kw)
Hydraulic motor 3HP (2.2kw)
Max. rolling pressure 17tons
